FSC Series - Flat Silicone Caps
- Reduces Creepage in Applications Where Temperatures Change Rapidly
- Flexible Enough to Conform to Irregular Geometry
- Flat Top Aids Insertion and Minimizes any Air Trap
- Flat Silicone Caps are Reusable, and Will Not Melt or Harden
Product Description:
Used as a cap over threaded studs, dowels, and protrusions. Our Flat Silicone Cap (FSC) product line is an alternative to our Silicone Cap (SC) product line for capping applications. Their versatile nature allows them to fit over extrusions, threaded studs, PEMS and dowels. Our high temperature Silicone is specially formulated to ensure reusability and economy during masking.
Helpful Hints:
- Alternate to many Silicone Cap (SC) sizes.
- When sizing parts as a cap, the ID of the cap should be 2 - 5% smaller than the stud diameter.
| Part Number | ID - IN | OD - IN | IL - IN | ID - MM | OD - MM | IL - MM | PCS/BAG | COLOR | Unit | Purchase | |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
0.070 (1.8mm) ID X 0.190" (4."
FSC 0070X1000-F
|
0.070 | 0.190 | 1.000 | 1.8 | 4.8 | 25.4 | 1000 | RUSTY |
$63.80/1000 Per BAG
|
||
|
0.100 (2.5mm) ID X 0.220" (5."
FSC 0100X1000-F
|
0.100 | 0.220 | 1.000 | 2.5 | 5.6 | 25.4 | 1000 | RUSTY |
$68.80/1000 Per BAG
|
||
|
0.120 (3.0mm) ID X 0.240" (6."
FSC 0120X0400-C
|
0.120 | 0.240 | 0.400 | 3.0 | 6.1 | 10.1 | 1000 | Clear |
$51.30/1000 Per BAG
|
||
|
0.148 (3.8mm) ID X 0.268" (6."
FSC 0148X1000-F
|
0.148 | 0.268 | 1.000 | 3.8 | 6.8 | 25.4 | 1000 | RUSTY |
$81.60/1000 Per BAG
|
||
|
0.175 (4.4mm) ID X 0.295" (7."
FSC 0175X1000-F
|
0.175 | 0.295 | 1.000 | 4.4 | 7.5 | 25.4 | 1000 | RUSTY |
$93.30/1000 Per BAG
|
||
|
0.223 (5.7mm) ID X 0.343" (8."
FSC 0223X1500-F
|
0.223 | 0.343 | 1.500 | 5.7 | 8.7 | 38.1 | 1000 | RUSTY |
$117.00/1000 Per BAG
|
||
|
0.355 (9.0mm) ID X 0.475" (12"
FSC 0355X1500-F
|
0.355 | 0.475 | 1.500 | 9.0 | 12.1 | 38.1 | 500 | RUSTY |
$99.85/500 Per BAG
|
||
|
0.375 (9.5mm) ID X 0.495" (12"
FSC 0375X1500-F
|
0.375 | 0.495 | 1.500 | 9.5 | 12.6 | 38.1 | 500 | RUSTY |
$77.61/500 Per BAG
|
||
|
0.456 (11.6mm) ID X 0.576" (1"
FSC 0456X1500-F
|
0.456 | 0.576 | 1.500 | 11.6 | 14.6 | 38.1 | 500 | RUSTY |
$112.02
$112.02/500 Per BAG
|
||
|
0.515 (13.1mm) ID X 0.635" (1"
FSC 0515X0728-C
|
0.515 | 0.635 | 0.728 | 13.1 | 16.1 | 18.5 | 250 | Clear |
$33.07/250 Per BAG
|
||
|
0.535 (13.6mm) ID X 0.655" (1"
FSC 0535X1500-F
|
0.535 | 0.655 | 1.500 | 13.6 | 16.6 | 38.1 | 250 | RUSTY |
$50.96/250 Per BAG
|
||
|
0.600 (15.2mm) ID X 0.720" (1"
FSC 0600X1500-F
|
0.600 | 0.720 | 1.500 | 15.2 | 18.3 | 38.1 | 250 | RUSTY |
$82.95/250 Per BAG
|
||
|
0.640 (16.3mm) ID X 0.760" (1"
FSC 0640X2000-B
|
0.640 | 0.760 | 2.000 | 16.3 | 19.3 | 50.8 | 250 | BLACK |
$74.59
$74.59/250 Per BAG
|
||
|
0.730 (18.5mm) ID X 0.850" (2"
FSC 0730X1500-F
|
0.730 | 0.850 | 1.500 | 18.5 | 21.6 | 38.1 | 250 | RUSTY |
$94.72/250 Per BAG
|
||
|
0.736 (18.7mm) ID X 0.856" (2"
FSC 0736X0728-C
|
0.736 | 0.856 | 0.728 | 18.7 | 21.7 | 18.5 | 250 | Clear |
$45.02/250 Per BAG
|
||
|
0.855 (21.7mm) ID X 0.975" (2"
FSC 0855X1500-F
|
0.855 | 0.975 | 1.500 | 21.7 | 24.8 | 38.1 | 250 | RUSTY |
$95.20
$95.20/250 Per BAG
|
||
|
0.980 (24.9mm) ID X 1.100" (2"
FSC 0980X1500-F
|
0.980 | 1.100 | 1.500 | 24.9 | 28.0 | 38.1 | 250 | RUSTY |
$90.15/250 Per BAG
|
||
|
1.106 (28.1mm) ID X 1.226" (3"
FSC 1106X0905-C
|
1.106 | 1.226 | 0.905 | 28.1 | 31.1 | 23.0 | 250 | Clear |
$76.29/250 Per BAG
|
||
|
1.291 (32.8mm) ID X 1.449 (36"
FSC 1291X0905-C
|
1.291 | 1.449 | 0.905 | 32.8 | 36.8 | 23.0 | 100 | Clear |
$36.89
$36.89/100 Per BAG
|
||
|
1.555 (39.5mm) ID X 1.673" (4"
FSC 1555X1102-C
|
1.555 | 1.675 | 1.102 | 39.5 | 42.5 | 28.0 | 100 | Clear |
$47.33/100 Per BAG
|
||
|
45.0mm X 54.0mm X 17.0mm X 20.
FSC 1772X0670-R
|
1.772 | 2.126 | 0.670 | 45.0 | 54.0 | 17.0 | 100 | Red |
$124.32/100 Per BAG
|
||
|
1.850 (47.0mm) ID X 1.949" (4"
FSC 1850X1102-C
|
1.850 | 1.970 | 1.102 | 47.0 | 50.0 | 28.0 | 100 | Clear |
$56.15
$56.15/100 Per BAG
|
